Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Body Style | Cylindrical |
| Cable Length | 2 m |
| Connection Type | Cable 4-Wire |
| Current, Switching | 200 mA |
| Frequency, Switching | 50 Hz |
| Housing Material | PBT |
| IP Rating | IP67 ; IP68 ; IP60 ; IP69K |
| Maximum Operating Temperature | 85 C |
| Measurement Range | 12 mm |
| Minimum Operating Temperature | -30 C |
| Mounting Type | M18 Threaded Non-Flush |
| Operating Temperature, Maximum | 85 C |
| Operating Temperature, Minimum | -30 C |
| Output | NPN-NO/NC |
| Primary Type | Capacitive Proximity Sensors |
| Series | |
| Shielding | Unshielded |
| Supply Voltage | 10-40 VDC |
| Type | Capacitive |
